i.e: if using the IBOX-MBS-KNX, KNX would be the External Protocol. TRADEMARKS: All trademarks and tradenames used in this document are acknowledged to be the copyright of their respective holders. External Protocol: Protocol that the IntesisBox integrates besides Modbus. The user interface of LinkBoxMB allows simulating the values of the Modbus registers without the need to be physically connected to the panel, very useful while in commissioning phase.
#Intesisbox modbus server knx software
IntesisBox Modbus Server series are configured using LinkBoxMB, a software tool for windows TM which is supplied along with the purchase of IntesisBox with no additional cost. Simple configuration, no point's configuration needs to be entered, just the communication parameters (IP address, baud rate…). Fixed Modbus address map, the register number identifies the element into the panel. Commands toward the panel are also supported (reset, silence, test elements…). The value in the Modbus register indicating the state of the panel's element is fully configurable. The IntesisBox Gateway has been specially designed to allow bidirectional control and monitoring of all parameters and functionalities of KNX installations from a Modbus BMS, SCADA, PLC or any other device working as a Modbus Master. Monitoring of the panel elements (detectors, outputs…) through independent Modbus registers. IntesisBox connects to the RS232 port of the Honeywell panel, either through the RS232 port of the mother board, or through the isolated ISO-RS232 port (optional card). IntesisBox is a server device in case of Modbus TCP communication, or a slave device in case of Modbus RTU communication.
IntesisBox allows Modbus TCP (Ethernet) or Modbus RTU (RS232 or RS485) communication, configurable by software. Master Modbus RTU LinkBoxMB Configuration Software Monitor & Control your network of XLS 80 fire panels remotely from your Control Center using any commercial SCADA or monitoring software with Modbus TCP driver. Integrate your Honeywell fire panels into your Modbus master device or system (SCADA, BMS, PLC, HMI, TouchPanels…). Cihaz Hakkında Daha Detaylı Bilgi İçin Tıklayınız.IntesisBox ® Modbus Server - Honeywell XLS 80 datasheet v10 r13 eng Gateway for integration of Honeywell XLS 80 fire panels into Modbus (RTU and TCP) enabled control systems. This useful feature allows actions on the same internal point from multiple KNX group addresses. The aim of this integration is to make accessible Modbus registers data and resources from a KNX system, as if it was a part of the own KNX system and vice-versa. Send a read request to the KNX bus when IntesisBox starts-up or after a KNX bus reset.įor each point, one KNX main group address and different listening group addresses can be defined. Integrate any Modbus RTU or TCP server device, or both at the same time, with any KNX device or system.Automatically send a write request to the KNX bus when its value changes.Any point in IntesisBox can be configured individually for different functionalities: The IntesisBox's KNX EIB interface connects directly to the EIB bus and it is optoisolated from the rest of the internal electronics.
On the KNX side, IntesisBox simulates a KNX device and acts as if it was a single device into the KNX system. Any point in IntesisBox can be configured individually for different functionality. The IntesisBoxs KNX EIB interface connects directly to the EIB bus and is optoisolated from the rest of the internal electronics. Points of Modbus devices can be read/written from KNX at any time. On the KNX side, IntesisBox simulates a KNX device and acts as if it was one more device into the KNX system. IntesisBox is a Modbus RTU Master and TCP Client device allowing to read/write points of other Modbus RTU Slave device(s) and Server device(s) connected to a Modbus network, offering these point's values through its KNX/EIB interface.įrom the Modbus system point of view, after the start-up process, IntesisBox reads continuously the points configured to be read in the Modbus Slave devices and updates in its memory all the values received from the Modbus system.
